Custom Special-shaped Quartz Sight Window for Korean Semiconductor Client-Amy

1. Project Overview

• Client: Korean manufacturer of semiconductor CVD & coating equipment components
• Product: Long strip fused silica sight window with integrated positioning bosses (as attached picture)
• Supplier: Lianyungang Shengfan Quartz Products Co., Ltd.
• Material: High-purity JGS2 fused silica
• Application: Observation window for high-temperature furnace chambers of thin-film deposition equipment, used for real-time visual inspection and temperature measurement
• Core Processes: CNC one-piece carving, corner chamfering, double-sided optical polishing, strict burr & chip-free edge finishing

2. Client’s Original Pain Points

1. Structural Defect from Bonding Process

   The client’s previous supplier only produced simple flat quartz strips. The 4 positioning pins at both ends had to be glued separately. Under long-term high-temperature operation, adhesive layers peeled off and released impurities, which contaminated the furnace chamber and reduced semiconductor production yield.
2. Strict Requirements on Heat Resistance & Light Transmittance

   The equipment runs continuously at 800–1100°C. Low-purity ordinary quartz turns yellow and devitrifies at high heat, disturbing infrared temperature detection. The client required high transmittance within 300–2500nm and impurity content below 10ppm.
3. Ultra-Tight Dimensional Tolerance

   Total length tolerance: ±0.05mm; thickness uniformity ≤0.02mm; unified R1.5 chamfers; positioning boss diameter & height tolerance ≤0.03mm. The Korean equipment has tiny assembly clearances; minor dimension deviation would lead to assembly failure.
4. Unstable Lead Time

   Frequent rework by the former supplier delayed mass production schedules, bringing risk of production line shutdown. The client urgently needed a reliable quartz manufacturer for mass supply.
5. Complete Compliance Documentation

   Korean semiconductor factories implement strict audit standards. Every batch required material Test Certificate (TC), full dimension inspection report and factory test record merged into one single document for factory filing and customs clearance.

3. Our Targeted Solutions & Advantages

1. One-Piece Integrated Forming, Eliminate Bonding

   We adopted precision CNC deep carving to shape the long window and four positioning bosses in one single process without any bonding seams. No peeling or volatile impurities under high temperature, fully meeting the cleanroom standards for semiconductor manufacturing.
2. Premium JGS2 High-Purity Raw Material

   JGS2 silica features low hydroxyl content and excellent optical performance. The finished window avoids fogging or yellowing during long high-temperature service, with full spectrum transmittance test data provided to support temperature monitoring.
3. Multi-Stage Precision Quality Control

• Three rounds of full inspection after cutting, carving and polishing;
• 3D coordinate measuring machine for sampling length, thickness and boss sizes to guarantee tolerance within ±0.05mm;
• 100% visual inspection to eliminate scratches, pits and edge chips, preventing thermal stress cracking at high heat.

4. Dedicated Production Line to Shorten Lead Time

   We arranged an exclusive processing line for semiconductor quartz parts to prioritize Korean orders. Samples can be delivered within 7 working days, and mass orders finished within 12 days after production, inspection and packaging to avoid client production suspension.
5. Standardized Combined Compliance Documents

   We integrated material TC certificate, dimensional inspection report and factory quality record into one bilingual English-Korean file as requested, directly applicable for factory audits and Korean import customs clearance.

4. Cooperation Results & Client Feedback

1. Stable Product Performance

   After 3 consecutive months of high-temperature furnace testing, the quartz sight windows showed no peeling, devitrification or transmittance attenuation. The core failure issue caused by bonded pins was completely solved, and the client’s semiconductor yield was significantly improved.
2. Stable Recurring Mass Orders

   After successful trial order of 500 pcs, the client signed a quarterly framework agreement, placing regular bulk orders of 2,000–3,500 pieces per month. They also expanded cooperation to other quartz components including quartz flanges, furnace tubes and wafer carriers.
3. Word-of-Mouth Referrals

   This Korean client recommended our factory to two local semiconductor equipment manufacturers, helping us expand market share in Korea’s high-purity quartz component sector.
4. High Recognition of Overall Service

   The client commented that we offer fast drawing communication, consistent dimensional accuracy, standardized documents and reliable lead time. Compared with their previous supplier, their comprehensive procurement cost was reduced by 12%, with zero after-sales rework disputes.

5. Case Summary & Market Insight

1. Core Demands of Korean Semiconductor Buyers

   They prioritize high purity, ultra-precise tolerance, bonding-free clean structure, complete test documentation and stable delivery schedules, with rigorous standards for product consistency and import compliance files.
2. Core Competitive Edge

   Our one-piece CNC carving technology differentiates us from ordinary quartz factories, perfectly matching customized component demands of high-end CVD, coating and diffusion furnace equipment manufacturers in South Korea.
3. Business Development Strategy for Similar Clients

   For Korean thin-film and semiconductor equipment manufacturers, promote integrated custom quartz sight windows and wafer carriers, and provide unified combined test certificates to fully match local factory audit rules.
